仿写Dubbo-MyRpc

基础

在仿写Dubbo之前，需要了解一些技术，像Java反射，Java代理，Java Socket以及Dubbo相关概念。

项目结构

项目gitee地址：https://gitee.com/AGi_R/framework

my-common

整个项目的公共资源库。存放一些公共的注解，类，接口，工具类等，供其他模块使用。

my-container

仿照tomcat的一些功能编写的项目运行容器。Sheep抽象类负责接收请求并分发，使用ServerSocket来接收请求，分发逻辑由my-framework编写。接收到一个请求之后创建一个新的线程来处理请求。在UrlMethodMapping中存放访问路径以及对应的方法相关信息，方法信息封装成MethodObject类。

my-framework

仿照spring boot编写的开发框架。编写了@MyService,@MyController,@MyRequestMapping,@MyAutowired和@MyApplication等注解。实现了IOC自动装配bean，MyRequestMapping请求处理，MyAutowired自动注入(只能注入类，无法注入接口)等功能。继承了Sheep抽象类，实现了请求分发功能。

my-registry

根据本项目需求编写的注册中心。实现了服务提供者注册，消费者订阅和消息推送等功能。每隔60秒对还在运行的消费者推送提供者列表。

⭐my-rpc

仿照dubbo编写的rpc框架。编写了@RpcReference和@RpcService注解，实现了其基本功能。实现了远程调用，负载均衡，服务提供者注册，服务消费者订阅等功能。

rpc-demo

my-framework的简单使用。

1.执行DemoApp的main方法启动项目

2.浏览器访问localhost:9527/进行测试

⭐rpc-api，rpc-consumer，rpc-provider

仿照dubbo项目结构搭建的微服务项目。rpc-api存放接口，rpc-consumer服务消费者，rpc-provider服务提供者。

1. 启动my-registry注册中心

2. 启动rpc-provider服务提供者

3. 启动rpc-consumer服务消费者

4. 浏览器访问localhost/demo/getUUID测试

my-rpc

annotation

存放的是框架使用的注解。@Rpc是修饰微服务项目启动类，有一个RpcType类型的必填参数type。@RpcService用来修饰服务提供者端的接口实现类。@RpcReference修饰服务消费者端需要远程调用的成员变量，value参数是被@RpcService修饰的类的全路径名。

@Documented
@Target(ElementType.TYPE)
@Retention(RetentionPolicy.RUNTIME)
public @interface Rpc {
    RpcType type();
}

@Documented
@Component    //存放在my-common里的公共注解
@Target(ElementType.TYPE)
@Retention(RetentionPolicy.RUNTIME)
public @interface RpcService {
}

@Documented
@Target(ElementType.FIELD)
@Retention(RetentionPolicy.RUNTIME)
public @interface RpcReference {
    /**
     * 被@RpcService修饰的类的全路径名
     * 例:com.agi.rpc.annotation.RpcReference
     * @return String
     *
     * @author aji
     * @date 2023/1/25 11:47
     */
    String value();
}

enums

RpcType枚举类，是@Rpc的参数类型，表明当前项目是CONSUMER或者PROVIDER。

public enum RpcType {
    PROVIDER, CONSUMER;
}

handler

是存放处理类的包。RpcReferenceHandler是给被@RpcReference修饰的成员变量赋值用的处理类。

public class RpcReferenceHandler {
    public static void assignReferenceValue() {
        for (Map.Entry<String, Bean> entry : IOC.getBeanMap().entrySet()) {
            Bean bean = entry.getValue();
            for (Field declaredField : bean.getClazz().getDeclaredFields()) {
                if (declaredField.isAnnotationPresent(RpcReference.class)) {
                    RpcReference reference = declaredField.getDeclaredAnnotation(RpcReference.class);
                    declaredField.setAccessible(true);
                    Object value = RpcProxy.getInstance(declaredField.getType(), reference.value());
                    try {
                        declaredField.set(bean.getInstance(), value);
                    } catch (Exception e) {
                        e.printStackTrace();
                    }
                }
            }
        }
    }
}

RpcRegistryHandler是向注册中心注册服务或者订阅服务用的处理类。

public class RpcRegistryHandler {
    //提供者列表
    private static List<ServiceProvider> providers = new ArrayList<>();

    private static void handler(RegistryRequestType type, InetAddress registryHost, int registryPort, InetAddress thisHost, int thisPort, String thisServiceName) {
        try {
            Socket socket = new Socket(registryHost, registryPort);
            OutputStream outputStream = socket.getOutputStream();
            ObjectOutputStream objectOutputStream = new ObjectOutputStream(outputStream);
            RpcRegistryRequest request = new RpcRegistryRequest();
            request.setType(type);
            request.setHost(thisHost);
            request.setPort(thisPort);
            request.setServiceName(thisServiceName);
            objectOutputStream.writeObject(request);
            objectOutputStream.flush();

            InputStream inputStream = socket.getInputStream();
            ObjectInputStream objectInputStream = new ObjectInputStream(inputStream);
            Object object = objectInputStream.readObject();
            if (object instanceof RpcRegistryResponse) {
                RpcRegistryResponse response = (RpcRegistryResponse) object;
                providers = response.getProviderList();
            }
            objectInputStream.close();
            inputStream.close();
            objectOutputStream.close();
            outputStream.close();
            socket.close();

        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    public static void register(InetAddress registryHost, int registryPort, InetAddress thisHost, int thisPort, String thisServiceName) {
        handler(RegistryRequestType.PUT, registryHost, registryPort, thisHost, thisPort, thisServiceName);
    }

    public static void subscribe(InetAddress registryHost, int registryPort, InetAddress thisHost, int thisPort, String thisServiceName) {
        handler(RegistryRequestType.GET, registryHost, registryPort, thisHost, thisPort, thisServiceName);
        Invoker.setProviderList(providers);
    }
}

⭐proxy

存放代理，远程调用相关的类。RpcInvoker用来远程调用服务以及实现负载均衡的类。实现了随机访问和轮询两种策略。

public class RpcInvoker extends Invoker {
    //当前位置
    private static int index = 0;

    //随机访问
    private static int RandomBalance() {
        int size = providerList.size();
        Random random = new Random();
        return random.nextInt(size);
    }

    //轮询(队列询问)
    private static int QueueBalance() {
        int size = providerList.size();
        int temp = index % size;
        index++;
        return temp;
    }

    private static Socket connect() {
        Socket socket = null;
        try {
            if (providerList.size() == 0) {
                throw new RuntimeException("请启动提供者");
            }
            ServiceProvider provider = providerList.get(QueueBalance());
            socket = new Socket();
            socket.connect(new InetSocketAddress(provider.getHost(), provider.getPort()), 3000);
            if (!socket.isConnected()) {
                providerList.remove(index);
                connect();
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
        return socket;
    }

    //远程调用
    public static Object invoke(RpcProtocol protocol) {
        Object result = null;
        try {
            Socket socket = connect();
            //告诉提供者容器，发送的是rpc请求
            OutputStream outputStream = socket.getOutputStream();
            outputStream.write("rpc\n".getBytes(StandardCharsets.UTF_8));
            outputStream.flush();
            InputStream inputStream = socket.getInputStream();
            Scanner scanner = new Scanner(inputStream);
            String line = scanner.hasNext() ? scanner.nextLine() : "";
            if (line.equals("rpc")) {
                //发送正式数据
                ObjectOutputStream objectOutputStream = new ObjectOutputStream(socket.getOutputStream());
                objectOutputStream.writeObject(protocol);
                objectOutputStream.flush();
                //接收响应数据
                ObjectInputStream objectInputStream = new ObjectInputStream(socket.getInputStream());
                System.out.println(protocol);
                result = objectInputStream.readObject();
                //关闭请求
                objectInputStream.close();
                outputStream.close();
            }
            socket.close();
        } catch (Exception e) {
            e.printStackTrace();
        }
        return result;
    }
}

RpcProxy是代理类，代理的是被@Reference修饰的成员变量。

public class RpcProxy implements InvocationHandler {
    private String referenceValue;

    private RpcProxy(String referenceValue) {
        this.referenceValue = referenceValue;
    }

    /**
     * 远程调用逻辑
     * @param proxy
     * @param method
     * @param args
     *
     * @return Object
     *
     * @author aji
     * @date 2023/1/25 10:56
     */
    @Override
    public Object invoke(Object proxy, Method method, Object[] args) throws Throwable {
        //封装请求
        RpcProtocol protocol = new RpcProtocol();
        protocol.setClassName(referenceValue);
        protocol.setMethodName(method.getName());
        protocol.setParamTypes(method.getParameterTypes());
        protocol.setParams(args);
        //远程调用
        Object invoke = RpcInvoker.invoke(protocol);
        return invoke;
    }

    public static Object getInstance(Class clazz, String referenceValue) {
        RpcProxy handler = new RpcProxy(referenceValue);
        Object instance = Proxy.newProxyInstance(
                clazz.getClassLoader(),
                new Class[]{clazz},
                handler
        );
        return instance;
    }
}

RpcApplication类

是微服务项目启动开关，根据项目启动类上的@Rpc注解的type参数判断当前项目是消费者或者提供者并调用相关逻辑。

public class RpcApplication {
    public static void run(Class mainClass, InetAddress registryHost, int registryPort, InetAddress thisHost, int thisPort, String thisServiceName) {
        if (mainClass.isAnnotationPresent(Rpc.class)) {
            Rpc rpc = (Rpc) mainClass.getDeclaredAnnotation(Rpc.class);
            if (rpc.type() == RpcType.CONSUMER) {
                //订阅
                RpcRegistryHandler.subscribe(registryHost, registryPort, thisHost, thisPort, thisServiceName);
                RpcReferenceHandler.assignReferenceValue();
            } else {
                //注册
                RpcRegistryHandler.register(registryHost, registryPort, thisHost, thisPort, thisServiceName);
            }
        } else {
            throw new RuntimeException("请添加@Rpc注解");
        }
    }
}
