WevSocket(java基于spring框架实现)

一、概述

本文基于spring-boot-starter-websocket简单的完成收发信息功能，使用spring框架进行实现。

二、相关配置

spring:2.0.2，jdk:1.8.202，maven:3.3.9

因为spring和maven有版本匹配的要求，请大家注意自己的版本是否匹配

三、项目结构

四、代码

1.启动类

SocketDemoApplication

package com.lp.socketdemo;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.context.annotation.Bean;
import org.springframework.scheduling.annotation.EnableScheduling;
import org.springframework.scheduling.concurrent.ThreadPoolTaskScheduler;

@EnableScheduling
@SpringBootApplication
public class SocketDemoApplication {

    public static void main(String[] args) {
        SpringApplication.run(SocketDemoApplication.class, args);
    }

    //处理定时任务报错问题
    @Bean
    public ThreadPoolTaskScheduler taskScheduler(){
        ThreadPoolTaskScheduler taskScheduler = new ThreadPoolTaskScheduler();
        taskScheduler.setPoolSize(10);
        taskScheduler.initialize();
        return taskScheduler;
    }
}

2.握手拦截器

package com.lp.socketdemo.spring;

import lombok.extern.slf4j.Slf4j;
import org.springframework.http.server.ServerHttpRequest;
import org.springframework.http.server.ServerHttpResponse;
import org.springframework.stereotype.Component;
import org.springframework.web.socket.WebSocketHandler;
import org.springframework.web.socket.server.support.HttpSessionHandshakeInterceptor;

import java.util.Map;

/**
 * 握手拦截器
 */
@Component
public class MyInterceptor extends HttpSessionHandshakeInterceptor {

    @Override
    public boolean beforeHandshake(ServerHttpRequest request, ServerHttpResponse response, WebSocketHandler wsHandler, Map<String, Object> attributes) throws Exception {
        System.out.println(request.getRemoteAddress().toString()+"开始握手");
        return super.beforeHandshake(request, response, wsHandler, attributes);
    }

    @Override
    public void afterHandshake(ServerHttpRequest request, ServerHttpResponse response, WebSocketHandler wsHandler, Exception ex) {
        System.out.println(request.getRemoteAddress().toString()+"完成握手");
        super.afterHandshake(request, response, wsHandler, ex);
    }
}

3.websocket主程序

package com.lp.socketdemo.spring;

import org.springframework.scheduling.annotation.Scheduled;
import org.springframework.stereotype.Component;
import org.springframework.web.socket.CloseStatus;
import org.springframework.web.socket.TextMessage;
import org.springframework.web.socket.WebSocketSession;
import org.springframework.web.socket.handler.AbstractWebSocketHandler;

import java.io.IOException;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.atomic.AtomicInteger;

/**
 * websocket 主程序
 */
@Component
public class MyWsHandler extends AbstractWebSocketHandler {

    private static Map<String,SessionBean> map;
    private static AtomicInteger clientIdMaker;
    static {
        map = new ConcurrentHashMap<>();
        clientIdMaker = new AtomicInteger(0);
    }

    /**
     * 连接建立
     * @param session
     * @throws Exception
     */
    @Override
    public void afterConnectionEstablished(WebSocketSession session) throws Exception {
        SessionBean sb = new SessionBean(session,clientIdMaker.getAndIncrement());
        map.put(session.getId(),sb);
        System.out.println(map.get(session.getId()).getClientId() +":建立连接");
        super.afterConnectionEstablished(session);
    }

    /**
     * 接收信息
     * @param session
     * @param message
     * @throws Exception
     */
    @Override
    protected void handleTextMessage(WebSocketSession session, TextMessage message) throws Exception {
        super.handleTextMessage(session, message);
        System.out.println(map.get(session.getId()).getClientId() +":"+message.getPayload());
    }

    /**
     * 传输异常
     * @param session
     * @param exception
     * @throws Exception
     */
    @Override
    public void handleTransportError(WebSocketSession session, Throwable exception) throws Exception {
        super.handleTransportError(session, exception);
        if(session.isOpen()) {
            session.close();
        }
        map.remove(session.getId());
    }

    /**
     * 连接关闭
     * @param session
     * @param status
     * @throws Exception
     */
    @Override
    public void afterConnectionClosed(WebSocketSession session, CloseStatus status) throws Exception {
        super.afterConnectionClosed(session, status);
        System.out.println(map.get(session.getId()).getClientId() +":关闭连接");
        map.remove(session.getId());
    }

    @Scheduled(fixedRate = 10000)
    public void sendMsg() throws IOException{
        for (String key: map.keySet()) {

                map.get(key).getWebSocketSession().sendMessage(new TextMessage("ws2心跳"));

        }
    }
}

4.配置类

package com.lp.socketdemo.spring;

import com.lp.socketdemo.java.WebSocketConfig;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.socket.config.annotation.EnableWebSocket;
import org.springframework.web.socket.config.annotation.WebSocketConfigurer;
import org.springframework.web.socket.config.annotation.WebSocketHandlerRegistry;

import javax.annotation.Resource;

@Configuration
@EnableWebSocket
public class MyWsConfig implements WebSocketConfigurer {

    @Resource
    MyWsHandler MyWsHandler;

    @Resource
    MyInterceptor myInterceptor;

    @Override
    public void registerWebSocketHandlers(WebSocketHandlerRegistry registry) {
        registry.addHandler(MyWsHandler,"/myWs2").addInterceptors(myInterceptor).setAllowedOrigins("*");
    }
}

5.封装实体类

package com.lp.socketdemo.spring;

import lombok.AllArgsConstructor;
import lombok.Data;
import org.springframework.stereotype.Component;
import org.springframework.web.socket.WebSocketSession;

@Component
public class SessionBean {
    private WebSocketSession webSocketSession;
    private int clientId;

    public SessionBean() {
    }

    public SessionBean(WebSocketSession webSocketSession, int clientId) {
        this.webSocketSession = webSocketSession;
        this.clientId = clientId;
    }

    public WebSocketSession getWebSocketSession() {
        return webSocketSession;
    }

    public void setWebSocketSession(WebSocketSession webSocketSession) {
        this.webSocketSession = webSocketSession;
    }

    public int getClientId() {
        return clientId;
    }

    public void setClientId(int clientId) {
        this.clientId = clientId;
    }
}

5.前段

websocketTest.html

<!DOCTYPE html>
<html>
<head>
  <meta http-equiv="Content-Type" content="text/html; charset=UTF-8">
  <title>websocket调试页面</title>
</head>
<script type="text/javascript" src="jquery.min.js"></script>
<body>
<div style="float: left; padding: 20px">
  <strong>location:</strong> <br />
  <input type="text" id="serverUrl" size="35" value="" /> <br />
  <button onclick="connect()">connect</button>
  <button onclick="wsclose()">disConnect</button>
  <br /> <strong>message:</strong> <br /> <input id="txtMsg" type="text" size="50" />
  <br />
  <button onclick="sendEvent()">发送</button>
</div>

<div style="float: left; margin-left: 20px; padding-left: 20px; width: 350px; border-left: solid 1px #cccccc;"> <strong>消息记录</strong>
  <div style="border: solid 1px #999999;border-top-color: #CCCCCC;border-left-color: #CCCCCC; padding: 5px;width: 100%;height: 172px;overflow-y: scroll;" id="echo-log"></div>
  <button onclick="clearLog()" style="position: relative; top: 3px;">清除消息</button>
</div>

</div>
</body>
<!-- 下面是h5原生websocket js写法 -->
<script type="text/javascript">
  let output ;
  let websocket;
  function connect(){ //初始化连接
    output = document.getElementById("echo-log")
    let inputNode = document.getElementById("serverUrl");
    let wsUri = inputNode.value;
    try{
		websocket = new WebSocket(wsUri);
    }catch(ex){
      console.log(ex)
      alert("对不起websocket连接异常")
    }

    connecting();
    window.addEventListener("load", connecting, false);
  }


  function connecting()
  {
    websocket.onopen = function(evt) { onOpen(evt) };
    websocket.onclose = function(evt) { onClose(evt) };
    websocket.onmessage = function(evt) { onMessage(evt) };
    websocket.onerror = function(evt) { onError(evt) };
  }

  function sendEvent(){
    let msg = document.getElementById("txtMsg").value
    doSend(msg);
  }

  //连接上事件
  function onOpen(evt)
  {
    writeToScreen("CONNECTED");
    doSend("WebSocket 已经连接成功！");
  }

  //关闭事件
  function onClose(evt)
  {
    writeToScreen("连接已经断开！");
  }

  //后端推送事件
  function onMessage(evt)
  {
    writeToScreen('<span style="color: blue;">服务器: ' + evt.data+'</span>');
  }

  function onError(evt)
  {
    writeToScreen('<span style="color: red;">异常信息:</span> ' + evt.data);
  }

  function doSend(message)
  {
    writeToScreen("客户端A: " + message);
    websocket.send(message);
  }

  //清除div的内容
  function clearLog(){
    output.innerHTML = "";
  }

  //浏览器主动断开连接
  function wsclose(){
    websocket.close();
  }

  function writeToScreen(message)
  {
    let pre = document.createElement("p");
    pre.innerHTML = message;
    output.appendChild(pre);
  }
</script>
</html>
