概述
WebRTC名称源自网页实时通信(Web Real-Time Communication)的缩写，是一个支持网页浏览器进行实时语音对话或视频对话的技术，是谷歌2010年以6820万美元收购Global IP Solutions公司而获得的一项技术。Google于2011年6月3日开源的即时通讯项目，旨在使其成为客户端视频通话的标准。其实在Google将WebRTC开源之前，微软和苹果各自的通讯产品已占用很大市场份额（如Skype），Google也是为了快速扩大市场，所以将他给开源。在行业内得到了广泛的支持和应用，成为下一代视频通话的标准。更多介绍可以去官网上看。
WebRTC被誉为是web长期开源开发的一个新启元，是近年来Web开发的最重要创新。WebRTC允许Web开发者在其web应用中添加视频聊天或者点对点数据传输，不需要复杂的代码或者昂贵的配置。目前支持Chrome、Firefox和Opera，后续会支持更多的浏览器，它有能力达到数十亿的设备。
目前，WebRTC的应用已经不局限在浏览器与浏览器之间，通过官方提供的SDK，我们可以很容易的实现本地应用间的音视频传输。在Android平台上，我们也非常容易的集成WebRTC框架，用非常简洁的代码就能实现强大、可靠的音视频传输功能。
实现
说明
本文代码修改自meshenger-android
True P2P Voice- and video phone calls without the need for accounts or access to the Internet. There is no discovery mechanism, no meshing and no servers. Just scan each others QR-Code that will contain the contacts IP address. This works in many local networks such as community mesh networks, company networks or at home.
翻译如下:
真正的 P2P 语音和视频电话呼叫，无需帐户或访问互联网。 没有发现机制，没有网格化，也没有服务器。 只需相互扫描包含联系人 IP 地址的二维码即可。 这适用于许多本地网络，例如社区网状网络、公司网络或家庭网络。
版本: meshenger-android-3.0.3 最后的JAVA版本, 最新版本已经改用kotlin
基本情况:
功能满足一个局域网P2P的视频通话功能
- 二维码身份生成-----正常
- 二维码扫码添加通讯录-----正常
- 连接发起通话------异常
主要问题在于无法创建两端之间的Socket连接, 与WebRTC本身无关 - 通讯加解密 ----- 异常
- 视频通话 ---- 只显示对方视频不显示自身
感谢作者
- 增加WebRtc支持
build.gradle
dependencies {
implementation 'org.webrtc:google-webrtc:1.0.32006'
}
- 关键代码及应用
创建 PeerConnectionFactory
private void initRTC() {
log("initRTC");
eglCtxRemote = EglBase.create().getEglBaseContext();
eglCtxLocal = EglBase.create().getEglBaseContext();
//创建 PeerConnectionFactory
//这种方法存在兼容性问题, 在一些平台上, 会导致后续流程不能正常执行.
/*PeerConnectionFactory.initialize(PeerConnectionFactory
.InitializationOptions.builder(context)
.createInitializationOptions());
factory = PeerConnectionFactory.builder().createPeerConnectionFactory();*/
constraints = new MediaConstraints();
constraints.optional.add(new MediaConstraints.KeyValuePair("offerToReceiveAudio", "true"));
constraints.optional.add(new MediaConstraints.KeyValuePair("offerToReceiveVideo", "true"));
constraints.optional.add(new MediaConstraints.KeyValuePair("DtlsSrtpKeyAgreement", "true"));
//initVideoTrack();
PeerConnectionFactory.initialize(PeerConnectionFactory.InitializationOptions.builder(context).createInitializationOptions());
PeerConnectionFactory.Options options = new PeerConnectionFactory.Options();
//https://yuriyshea.com/archives/androidwebrtc%E8%B8%A9%E5%9D%91%E6%8C%87%E5%8D%97
DefaultVideoEncoderFactory enVdf = new DefaultVideoEncoderFactory(eglCtxRemote, true, true);
VideoDecoderFactory deVdf = new DefaultVideoDecoderFactory(eglCtxRemote);
//创建 PeerConnectionFactory
factory = PeerConnectionFactory.builder()
.setOptions(options)
.setVideoEncoderFactory(enVdf)
.setVideoDecoderFactory(deVdf)
.createPeerConnectionFactory();
log("initRTC done");
}
创建PeerConnection 发起呼叫
connection = factory.createPeerConnection(Collections.emptyList(), new DefaultObserver() {
@Override
public void onIceGatheringChange(PeerConnection.IceGatheringState iceGatheringState) {
super.onIceGatheringChange(iceGatheringState);
log("Outgoing.onIceGatheringChange " + iceGatheringState.name());
if (iceGatheringState == PeerConnection.IceGatheringState.COMPLETE) {
log("Outgoing.connect call from remote address: " + contact.getAddresses());
reportStateChange(CallState.CONNECTING);
//发送信息给接收方,告知发起通话.
getPublisher().sendCall(contact.getAddresses(), connection.getLocalDescription().description);
}
@Override
public void onIceConnectionChange(PeerConnection.IceConnectionState iceConnectionState) {
log("Outgoing.onIceConnectionChange " + iceConnectionState.name());
super.onIceConnectionChange(iceConnectionState);
if (iceConnectionState == PeerConnection.IceConnectionState.DISCONNECTED) {
reportStateChange(CallState.DISCONNECTED);
}else if (iceConnectionState == PeerConnection.IceConnectionState.CLOSED) {
hangUp("Outgoing.onIceConnectionChange CLOSED");
}
}
@Override
public void onAddStream(MediaStream mediaStream) {
log("Outgoing.onAddStream");
super.onAddStream(mediaStream);
handleMediaStream(mediaStream);
}
@Override
public void onDataChannel(DataChannel dataChannel) {
log("Outgoing.onDataChannel");
super.onDataChannel(dataChannel);
RTCCall.this.dataChannel = dataChannel;
dataChannel.registerObserver(RTCCall.this);
}
});
//初始化音视频通道
connection.addStream(createStream());
//创建数据通道, 可用于收发消息.
this.dataChannel = connection.createDataChannel("data", new DataChannel.Init());
this.dataChannel.registerObserver(this);
log("Outgoing.createOffer");
connection.createOffer(new DefaultSdpObserver() {
@Override
public void onCreateSuccess(SessionDescription sessionDescription) {
log("Outgoing.onCreateSuccess");
super.onCreateSuccess(sessionDescription);
connection.setLocalDescription(new DefaultSdpObserver(), sessionDescription);
}
}, constraints);
呼叫方收到后同样初始化, 并在点击接听后创建PeerConnection
public void accept(OnStateChangeListener listener) {
log("accept");
this.listener = listener;
new Thread(() -> {
connection = factory.createPeerConnection(this.iceServers, new DefaultObserver() {
@Override
public void onIceGatheringChange(PeerConnection.IceGatheringState iceGatheringState) {
super.onIceGatheringChange(iceGatheringState);
if (iceGatheringState == PeerConnection.IceGatheringState.COMPLETE) {
log("Incoming.onIceGatheringChange");
//通知已接听
getPublisher().sendAnswer(contact.getAddresses(),
connection.getLocalDescription().description);
reportStateChange(CallState.CONNECTED);
}
}
@Override
public void onIceConnectionChange(PeerConnection.IceConnectionState iceConnectionState) {
log("Incoming.onIceConnectionChange " + iceConnectionState.name());
super.onIceConnectionChange(iceConnectionState);
if (iceConnectionState == PeerConnection.IceConnectionState.DISCONNECTED) {
reportStateChange(CallState.DISCONNECTED);
}else if (iceConnectionState == PeerConnection.IceConnectionState.CLOSED) {
hangUp("Incoming.onIceConnectionChange CLOSED");
}
}
@Override
public void onAddStream(MediaStream mediaStream) {
log("Incoming.onAddStream");
super.onAddStream(mediaStream);
handleMediaStream(mediaStream);
}
@Override
public void onDataChannel(DataChannel dataChannel) {
super.onDataChannel(dataChannel);
RTCCall.this.dataChannel = dataChannel;
dataChannel.registerObserver(RTCCall.this);
}
});
connection.addStream(createStream());
//this.dataChannel = connection.createDataChannel("data", new DataChannel.Init());
log("Incoming.setting remote description");
//设置会话, 创建响应应答
connection.setRemoteDescription(new DefaultSdpObserver() {
@Override
public void onSetSuccess() {
super.onSetSuccess();
log("creating answer...");
connection.createAnswer(new DefaultSdpObserver() {
@Override
public void onCreateSuccess(SessionDescription sessionDescription) {
log("Incoming.onCreateSuccess");
super.onCreateSuccess(sessionDescription);
connection.setLocalDescription(new DefaultSdpObserver(), sessionDescription);
}
@Override
public void onCreateFailure(String s) {
super.onCreateFailure(s);
log("Incoming.onCreateFailure: " + s);
}
}, constraints);
}
}, new SessionDescription(SessionDescription.Type.OFFER, offer));
}).start();
}
呼叫方处理应答
private void handleAnswer(String remoteDesc) {
log("handleAnswer");
connection.setRemoteDescription(new DefaultSdpObserver() {
@Override
public void onSetSuccess() {
super.onSetSuccess();
}
@Override
public void onSetFailure(String s) {
super.onSetFailure(s);
}
}, new SessionDescription(SessionDescription.Type.ANSWER, remoteDesc));
}
启动摄像头
public void setVideoEnabled(boolean enabled) {
log("setVideoEnabled enabled=" + enabled);
this.videoEnabled = enabled;
try {
if (enabled) {
this.capturer.startCapture(640, 480, 30);
} else {
this.capturer.stopCapture();
}
JSONObject object = new JSONObject();
object.put(StateChangeMessage, enabled ? CameraEnabledMessage : CameraDisabledMessage);
log("setVideoEnabled: " + object);
dataChannel.send(new DataChannel.Buffer(ByteBuffer.wrap(object.toString().getBytes()), false));
} catch (JSONException e) {
e.printStackTrace();
} catch (InterruptedException e) {
e.printStackTrace();
}
}
挂断
public void hangUp(String res) {
if(state == CallState.ENDED){
log("hangUp Ignored already ENDED:" + res);
return;
}
log("hangUp:" + res);
reportStateChange(CallState.ENDED);
closePeerConnection();
//通知挂断.
new Thread(() -> {
getPublisher().sendHangup(contact.getAddresses());
}).start();
}
//Fatal signal 11 (SIGSEGV), code 1 (SEGV_MAPERR), fault addr 0x0 in tid 13128 (signaling_threa), pid 13067 (d.d.meshenger)
//type=1400 audit(0.0:28585): avc: granted { nlmsg_readpriv } for scontext=u:r:untrusted_app_29:s0:c5,c257,c512,c768 tcontext=u:r:untrusted_app_29:s0:c5,c257,c512,c768 tclass=netlink_route_socket app=d.d.meshenger
//pid: 13067, tid: 13128, name: signaling_threa >>> d.d.meshenger <<<
private void closePeerConnection() {
log("closePeerConnection");
if(localRenderer != null){
localRenderer.release();
localRenderer = null;
}
if(remoteRenderer != null){
remoteRenderer.release();
remoteRenderer = null;
}
if(capturer != null){
try {
capturer.stopCapture();
capturer.dispose();
capturer = null;
} catch (InterruptedException e) {
e.printStackTrace();
}
}
if (connection != null) {
try {
PeerConnection conn = connection;
connection = null;
conn.close();
} catch (Exception e) {
e.printStackTrace();
}
//connection = null;
log("closePeerConnection done");
}
}
完整呼叫流程LOG如下
[呼叫方]
## 开始呼出
2022-12-01 14:50:09.016 23145-23717 RTCCall D RTCCall created
2022-12-01 14:50:09.016 23145-23717 RTCCall D initRTC
2022-12-01 14:50:09.041 23145-23717 RTCCall D initRTC done
2022-12-01 14:50:09.042 23145-23728 RTCCall D createPeerConnection
2022-12-01 14:50:09.052 23145-23728 RTCCall D createStream
2022-12-01 14:50:09.058 23145-23728 RTCCall D createCapturer
2022-12-01 14:50:09.139 23145-23728 RTCCall D Outgoing.createOffer
2022-12-01 14:50:09.144 23145-23725 RTCCall D Outgoing.onCreateSuccess
2022-12-01 14:50:09.212 23145-23725 RTCCall D Outgoing.onIceGatheringChange GATHERING
2022-12-01 14:50:09.327 23145-23725 RTCCall D Outgoing.onIceGatheringChange COMPLETE
2022-12-01 14:50:09.327 23145-23725 RTCCall D transferring offer...
2022-12-01 14:50:09.328 23145-23735 RTCCall D Outgoing.connect call from remote address: 192.168.7.239
2022-12-01 14:50:09.328 23145-23735 RTCCall D reportStateChange CONNECTING
## 对方接听
2022-12-01 14:50:15.331 23145-23168 RTCCall D reportStateChange CONNECTED
2022-12-01 14:50:15.331 23145-23168 RTCCall D handleAnswer
2022-12-01 14:50:15.409 23145-23725 RTCCall D Outgoing.onIceConnectionChange CHECKING
2022-12-01 14:50:15.415 23145-23725 RTCCall D Outgoing.onAddStream
2022-12-01 14:50:15.415 23145-23725 RTCCall D handleMediaStream ava=false
2022-12-01 14:50:15.416 23145-23725 RTCCall D handleAnswer.onSetSuccess
2022-12-01 14:50:15.512 23145-23725 RTCCall D Outgoing.onIceConnectionChange CONNECTED
2022-12-01 14:50:15.528 23145-23725 RTCCall D onStateChange
## 对方开启摄像头, 并推送
2022-12-01 14:50:24.939 23145-23725 RTCCall D onMessage: {"StateChange":"CameraEnabled"}
2022-12-01 14:50:30.932 23145-23725 RTCCall D Outgoing.onIceConnectionChange COMPLETED
## 开启摄像头并推送
2022-12-01 14:50:39.122 23145-23145 RTCCall D setVideoEnabled enabled=true
2022-12-01 14:50:39.122 23145-23145 RTCCall D setVideoEnabled: {"StateChange":"CameraEnabled"}
2022-12-01 14:50:39.124 23145-23725 RTCCall D onBufferedAmountChange l=31
## 挂断
2022-12-01 14:51:03.363 23145-23145 RTCCall D hangUp:UI.callDecline click
2022-12-01 14:51:03.363 23145-23145 RTCCall D reportStateChange ENDED
2022-12-01 14:51:03.363 23145-23145 RTCCall D closePeerConnection
2022-12-01 14:51:03.370 23145-23145 RTCCall D closePeerConnection state=CONNECTED
2022-12-01 14:51:03.372 23145-23725 RTCCall D Outgoing.onIceConnectionChange CLOSED
2022-12-01 14:51:03.372 23145-23725 RTCCall D hangUp Ignored already ENDED:Outgoing.onIceConnectionChange CLOSED
2022-12-01 14:51:03.547 23145-23725 RTCCall D onStateChange
2022-12-01 14:51:03.547 23145-23725 RTCCall D onStateChange
2022-12-01 14:51:03.580 23145-23145 RTCCall D closePeerConnection done
2022-12-01 14:51:04.059 23145-23145 RTCCall D releaseCamera
2022-12-01 14:51:04.149 23145-23168 RTCCall D hangUp Ignored already ENDED:publisher msg
[被叫方]
## 来电并响铃
2022-12-01 14:22:30.319 8916-8943 RTCCall D initRTC
2022-12-01 14:22:30.363 8916-8943 RTCCall D initRTC done
2022-12-01 14:22:30.364 8916-8943 RTCCall D reportStateChange RINGING
## 接听
2022-12-01 14:22:35.625 8916-8916 RTCCall D setRenderer
2022-12-01 14:22:35.625 8916-8916 RTCCall D accept
2022-12-01 14:22:35.661 8916-14310 RTCCall D createStream
2022-12-01 14:22:35.662 8916-14310 RTCCall D createCapturer
2022-12-01 14:22:35.677 8916-14310 RTCCall D Incoming.setting remote description
2022-12-01 14:22:35.768 8916-14256 RTCCall D Incoming.onAddStream
2022-12-01 14:22:35.768 8916-14256 RTCCall D handleMediaStream ava=false
2022-12-01 14:22:35.769 8916-14256 RTCCall D creating answer...
2022-12-01 14:22:35.773 8916-14256 RTCCall D Incoming.onCreateSuccess
2022-12-01 14:22:35.873 8916-14256 RTCCall D Incoming.onIceConnectionChange CHECKING
2022-12-01 14:22:36.035 8916-14256 RTCCall D Incoming.onIceGatheringChange
## 连接已建立
2022-12-01 14:22:36.048 8916-14256 RTCCall D reportStateChange CONNECTED
2022-12-01 14:22:36.256 8916-14256 RTCCall D Incoming.onIceConnectionChange CONNECTED
2022-12-01 14:22:36.278 8916-14256 RTCCall D onStateChange
## 开启摄像头并推送
2022-12-01 14:22:45.635 8916-8916 RTCCall D setVideoEnabled enabled=true
2022-12-01 14:22:45.636 8916-8916 RTCCall D setVideoEnabled: {"StateChange":"CameraEnabled"}
2022-12-01 14:22:45.638 8916-14256 RTCCall D onBufferedAmountChange l=31
## 对方开启摄像头
2022-12-01 14:23:02.916 8916-14256 RTCCall D onMessage: {"StateChange":"CameraEnabled"}
## 对方已挂断
2022-12-01 14:23:24.318 8916-14256 RTCCall D Incoming.onIceConnectionChange DISCONNECTED
2022-12-01 14:23:24.318 8916-14256 RTCCall D reportStateChange DISCONNECTED
2022-12-01 14:23:24.320 8916-14256 RTCCall D onStateChange
2022-12-01 14:23:24.320 8916-14256 RTCCall D onStateChange
2022-12-01 14:23:24.430 8916-8943 RTCCall D hangUp:publisher msg
2022-12-01 14:23:24.430 8916-8943 RTCCall D reportStateChange ENDED
2022-12-01 14:23:24.431 8916-8943 RTCCall D closePeerConnection
2022-12-01 14:23:24.445 8916-8943 RTCCall D closePeerConnection state=CONNECTED
2022-12-01 14:23:24.449 8916-14256 RTCCall D Incoming.onIceConnectionChange CLOSED
2022-12-01 14:23:24.449 8916-14256 RTCCall D hangUp Ignored already ENDED:Incoming.onIceConnectionChange CLOSED
2022-12-01 14:23:24.705 8916-8943 RTCCall D closePeerConnection done
2022-12-01 14:23:24.924 8916-8916 RTCCall D releaseCamera
一些问题
首先是源码中Socket连接的问题
Utils.java 与IPV6有关, 这里改成了IPV4.
并在后续的网络相关部分改为使用IP地址.
public static List<InetSocketAddress> getAddressPermutations(String contact_mac, int port) {
byte[] contact_mac_bytes = Utils.macAddressToBytes(contact_mac);
ArrayList<InetSocketAddress> addrs = new ArrayList<InetSocketAddress>();
try {
List<NetworkInterface> all = Collections.list(NetworkInterface.getNetworkInterfaces());
for (NetworkInterface nif : all) {
if (nif.isLoopback()) {
continue;
}
for (InterfaceAddress ia : nif.getInterfaceAddresses()) {
InetAddress addr = ia.getAddress();
if (addr.isLoopbackAddress()) {
continue;
}
android.util.Log.d("Utils", "getAddressPermutations " + addr.getHostName() + "," + addr.getHostAddress() + ",");
if (addr instanceof Inet4Address) {
addrs.add(new InetSocketAddress(addr, port));
/*Inet6Address addr6 = (Inet6Address) addr;
byte[] extracted_mac = getEUI64MAC(addr6);
if (extracted_mac != null && Arrays.equals(extracted_mac, nif.getHardwareAddress())) {
// We found the interface MAC address in the IPv6 assigned to that interface in the EUI-64 scheme.
// Now assume that the contact has an address with the same scheme.
InetAddress new_addr = createEUI64Address(addr6, contact_mac_bytes);
if (new_addr != null) {
addrs.add(new InetSocketAddress(new_addr, port));
}
}*/
}
}
}
} catch (Exception e) {
e.printStackTrace();
}
增加本地摄像头预览显示
方法是传入本地的SurfaceViewRenderer并修改getVideoTrack
private boolean enablePreview = true;
private VideoTrack getVideoTrack() {
this.capturer = createCapturer();
if(!enablePreview) {
return factory.createVideoTrack("video1", factory.createVideoSource(false));
}else {
VideoSource videoSource = factory.createVideoSource(false);
//EglBase.Context eglBaseContext = EglBase.create().getEglBaseContext();
SurfaceTextureHelper surfaceTextureHelper = SurfaceTextureHelper.create("CaptureThread", eglCtxLocal);
capturer.initialize(surfaceTextureHelper, App.getApp(), videoSource.getCapturerObserver());
//capturer.startCapture(480, 640, 30);
VideoTrack track = factory.createVideoTrack("video1", videoSource);
track.addSink(localRenderer);
return track;
}
}
初始化方式问题导致无正常回调
constraints = new MediaConstraints();
constraints.optional.add(new MediaConstraints.KeyValuePair("offerToReceiveAudio", "true"));
constraints.optional.add(new MediaConstraints.KeyValuePair("offerToReceiveVideo", "true"));
constraints.optional.add(new MediaConstraints.KeyValuePair("DtlsSrtpKeyAgreement", "true"));
//方式1:
PeerConnectionFactory.initialize(PeerConnectionFactory
.InitializationOptions.builder(context)
.createInitializationOptions());
factory = PeerConnectionFactory.builder().createPeerConnectionFactory();
//方式2:
PeerConnectionFactory.initialize(PeerConnectionFactory.InitializationOptions.builder(context).createInitializationOptions());
PeerConnectionFactory.Options options = new PeerConnectionFactory.Options();
DefaultVideoEncoderFactory enVdf = new DefaultVideoEncoderFactory(eglCtxRemote, true, true);
VideoDecoderFactory deVdf = new DefaultVideoDecoderFactory(eglCtxRemote);
factory = PeerConnectionFactory.builder()
.setOptions(options)
.setVideoEncoderFactory(enVdf)
.setVideoDecoderFactory(deVdf)
.createPeerConnectionFactory();
方式1 会导致呼出时的错误如下
connection.createOffer(new DefaultSdpObserver() {
@Override
public void onCreateSuccess(SessionDescription sessionDescription) {
log("Outgoing.onCreateSuccess");
super.onCreateSuccess(sessionDescription);
connection.setLocalDescription(new DefaultSdpObserver(){
@Override
public void onSetFailure(String s) {
super.onSetFailure(s);
//出错时的LOG:
//onSetFailure s=
//Failed to set local offer sdp:
//Failed to set local video description recv parameters for m-section with mid='video'.
log("Outgoing.onSetFailure s=" + s);
}
}, sessionDescription);
}
}, constraints);
多次调用PeerConnection.close()会导致崩溃
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Build fingerprint: 'google/blueline/blueline:12/SP1A.210812.016.C1/8029091:user/release-keys'
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Revision: 'MP1.0'
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A ABI: 'arm64'
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Timestamp: 2022-12-01 14:31:57.642912791+0800
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Process uptime: 0s
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Cmdline: d.d.meshenger
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A pid: 22778, tid: 22851, name: signaling_threa >>> d.d.meshenger <<<
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A uid: 10261
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A signal 11 (SIGSEGV), code 1 (SEGV_MAPERR), fault addr 0x0
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A Cause: null pointer dereference
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x0 0000000000000000 x1 0000000000000005 x2 0000000000000000 x3 0000007c6f2be89d
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x4 0000007c584fd818 x5 0000007f12e7a555 x6 73656d2f642f644c x7 632f7265676e6568
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x8 0000007be2f5a000 x9 81248e9b13f44bd4 x10 0000000000430000 x11 0000000000000001
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x12 0000000000000004 x13 0000000000000004 x14 7ffbffff00000000 x15 0000000000000000
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x16 0000007c584fcf00 x17 0000007f23435688 x18 0000007be1bc6000 x19 0000007d918a0910
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x20 0000000000000005 x21 0000007c584fe000 x22 0000007c584fd960 x23 0000007c584fe000
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x24 0000007be2f16ab8 x25 00000000ffffffff x26 0000007c584fdff8 x27 00000000000fc000
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A x28 0000007c58405000 x29 0000007c584fda10
2022-12-01 14:31:57.847 22887-22887 DEBUG pid-22887 A lr 0000007be34be6e0 sp 0000007c584fd950 pc 0000007be34be6f4 pst 0000000060000000
资源
源码及资料下载
Android WebRTC 的一些资料
参考
WebRTC
googlesource webrtc / src
git clone https://webrtc.googlesource.com/src (需要连接外网)
meshenger-android
WebRTC-Android 探索 - 创建音视频通话程序的基本姿势
WebRTC实现Android传屏demo
Android WebRTC踩坑指南
Google WebRtc Android 使用详解(包括客户端和服务端代码)
owt-client-android
android webrtc学习 一（源码下载和编译)
编译webrtc android源码
libwebrtc.aar
