Flink JobManager 内存占用大问题

问题描述

当在本地启动一个 flink 简单的 job 时候，发现出现了 heap outMemeory 问题，
然后就不假思索的调整了 jvm 的 heap -Xms1000m -Xmx16000m 参数，就可以正常的启动了。
通过 jvisualvm 连接上这个 jvm process，参看堆大小竟然达到了 4、5G。
flink jobManager 大内存 jvm 图1

解决过程

直到最近才有时间，来探究一下到底为什么要占用这么大的内存？

我们下去掉 jvm 配置的 heap -Xms1000m -Xmx16000m 参数，看看程序哪里报的错。

Exception in thread "main" com.yyb.flink.core.exception.StreamBasicException: Context submit error
	at com.yyb.flink.core.context.AbstractContextProxy.submit(AbstractContextProxy.java:72)
	at com.yyb.flink.core.context.AbstractContextProxy.submit(AbstractContextProxy.java:101)
	at com.yyb.flink.app.table.dim.dataGen.JoinWithDataGenTable.main(JoinWithDataGenTable.java:39)
Caused by: org.apache.flink.util.FlinkException: Failed to execute job 'JoinWithDataGenTable'.
	at org.apache.flink.streaming.api.environment.StreamExecutionEnvironment.executeAsync(StreamExecutionEnvironment.java:1969)
	at org.apache.flink.streaming.api.environment.StreamExecutionEnvironment.execute(StreamExecutionEnvironment.java:1847)
	at org.apache.flink.streaming.api.environment.LocalStreamEnvironment.execute(LocalStreamEnvironment.java:69)
	at org.apache.flink.streaming.api.environment.StreamExecutionEnvironment.execute(StreamExecutionEnvironment.java:1833)
	at com.yyb.flink.core.context.AbstractContextProxy.IfPresentSinkExecute(AbstractContextProxy.java:94)
	at com.yyb.flink.core.context.AbstractContextProxy.submit(AbstractContextProxy.java:69)
	... 2 more
Caused by: java.lang.RuntimeException: org.apache.flink.runtime.client.JobInitializationException: Could not start the JobMaster.
	at org.apache.flink.util.ExceptionUtils.rethrow(ExceptionUtils.java:316)
	at org.apache.flink.util.function.FunctionUtils.lambda$uncheckedFunction$2(FunctionUtils.java:75)
	at java.util.concurrent.CompletableFuture.uniApply(CompletableFuture.java:602)
	at java.util.concurrent.CompletableFuture$UniApply.tryFire(CompletableFuture.java:577)
	at java.util.concurrent.CompletableFuture$Completion.exec(CompletableFuture.java:443)
	at java.util.concurrent.ForkJoinTask.doExec(ForkJoinTask.java:289)
	at java.util.concurrent.ForkJoinPool$WorkQueue.runTask(ForkJoinPool.java:1056)
	at java.util.concurrent.ForkJoinPool.runWorker(ForkJoinPool.java:1692)
	at java.util.concurrent.ForkJoinWorkerThread.run(ForkJoinWorkerThread.java:157)
Caused by: org.apache.flink.runtime.client.JobInitializationException: Could not start the JobMaster.
	at org.apache.flink.runtime.jobmaster.DefaultJobMasterServiceProcess.lambda$new$0(DefaultJobMasterServiceProcess.java:97)
	at java.util.concurrent.CompletableFuture.uniWhenComplete(CompletableFuture.java:760)
	at java.util.concurrent.CompletableFuture$UniWhenComplete.tryFire(CompletableFuture.java:736)
	at java.util.concurrent.CompletableFuture.postComplete(CompletableFuture.java:474)
	at java.util.concurrent.CompletableFuture$AsyncSupply.run(CompletableFuture.java:1595)
	at java.util.concurrent.Executors$RunnableAdapter.call(Executors.java:511)
	at java.util.concurrent.FutureTask.run(FutureTask.java:266)
	at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.access$201(ScheduledThreadPoolExecutor.java:180)
	at java.util.concurrent.ScheduledThreadPoolExecutor$ScheduledFutureTask.run(ScheduledThreadPoolExecutor.java:293)
	at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1149)
	at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:624)
	at java.lang.Thread.run(Thread.java:748)
Caused by: java.util.concurrent.CompletionException: java.lang.OutOfMemoryError: Java heap space
	at java.util.concurrent.CompletableFuture.encodeThrowable(CompletableFuture.java:273)
	at java.util.concurrent.CompletableFuture.completeThrowable(CompletableFuture.java:280)
	at java.util.concurrent.CompletableFuture$AsyncSupply.run(CompletableFuture.java:1592)
	... 7 more
Caused by: java.lang.OutOfMemoryError: Java heap space
	at java.util.ArrayDeque.allocateElements(ArrayDeque.java:147)
	at java.util.ArrayDeque.<init>(ArrayDeque.java:203)
	at org.apache.flink.runtime.executiongraph.failover.flip1.FailureRateRestartBackoffTimeStrategy.<init>(FailureRateRestartBackoffTimeStrategy.java:59)
	at org.apache.flink.runtime.executiongraph.failover.flip1.FailureRateRestartBackoffTimeStrategy$FailureRateRestartBackoffTimeStrategyFactory.create(FailureRateRestartBackoffTimeStrategy.java:153)
	at org.apache.flink.runtime.scheduler.DefaultSchedulerFactory.createInstance(DefaultSchedulerFactory.java:97)
	at org.apache.flink.runtime.jobmaster.DefaultSlotPoolServiceSchedulerFactory.createScheduler(DefaultSlotPoolServiceSchedulerFactory.java:110)
	at org.apache.flink.runtime.jobmaster.JobMaster.createScheduler(JobMaster.java:340)
	at org.apache.flink.runtime.jobmaster.JobMaster.<init>(JobMaster.java:317)
	at org.apache.flink.runtime.jobmaster.factories.DefaultJobMasterServiceFactory.internalCreateJobMasterService(DefaultJobMasterServiceFactory.java:107)
	at org.apache.flink.runtime.jobmaster.factories.DefaultJobMasterServiceFactory.lambda$createJobMasterService$0(DefaultJobMasterServiceFactory.java:95)
	at org.apache.flink.runtime.jobmaster.factories.DefaultJobMasterServiceFactory$$Lambda$1246/1142234774.get(Unknown Source)
	at org.apache.flink.util.function.FunctionUtils.lambda$uncheckedSupplier$4(FunctionUtils.java:112)
	at org.apache.flink.util.function.FunctionUtils$$Lambda$1247/405573242.get(Unknown Source)
	at java.util.concurrent.CompletableFuture$AsyncSupply.run(CompletableFuture.java:1590)
	... 7 more

然后我们找到代码所在的位置：
FailureRateRestartBackoffTimeStrategy.class

FailureRateRestartBackoffTimeStrategy(
            Clock clock, int maxFailuresPerInterval, long failuresIntervalMS, long backoffTimeMS) {

        checkArgument(
                maxFailuresPerInterval > 0,
                "Maximum number of restart attempts per time unit must be greater than 0.");
        checkArgument(failuresIntervalMS > 0, "Failures interval must be greater than 0 ms.");
        checkArgument(backoffTimeMS >= 0, "Backoff time must be at least 0 ms.");

        this.failuresIntervalMS = failuresIntervalMS;
        this.backoffTimeMS = backoffTimeMS;
        this.maxFailuresPerInterval = maxFailuresPerInterval;
        this.failureTimestamps = new ArrayDeque<>(maxFailuresPerInterval);	//这里
        this.strategyString = generateStrategyString();
        this.clock = checkNotNull(clock);
    }

ArrayDeque.class

public ArrayDeque(int numElements) {
        allocateElements(numElements);
    }
private void allocateElements(int numElements) {
        elements = new Object[calculateSize(numElements)]; //这里
}

可以知道，如果这个 numElements、maxFailuresPerInterval 设置的比较大的话，那么这里就会直接申请这么大的 object数组，就有可能 heap OutOfMemoryError。
回想到我们曾经设置 flink FailureRateRestartStrategyConfiguration 的次数为 Integer.MAX_VALUE，那么就将通了。
为什么要设置这么大的失败重启次数，当时是因为下载 s3文件，时不时会出现 timeOut 问题，所以 flink 的 FailureRateRestartStrategyConfiguration 设置为 Integer.MAX_VALUE，没有想到致使 jobManager 的内存占用变得这么大了。

解决效果

设置 FailureRateRestartStrategyConfiguration 的次数为 3
flink jobManager 大内存 jvm 图2
设置 FailureRateRestartStrategyConfiguration 的次数为 10000.
flink jobManager 大内存 jvm 图3
