Cmake：Win10 如何编译 midifile C++应用程序

先从 Microsoft C++ Build Tools - Visual Studio

下载 1.73GB 安装 "Microsoft C++ Build Tools“

下载：midifile 项目 , 将 midifile-master.zip 解压到 D:\Music-soft

参阅: cmake超详细入门教程

CMake是一个跨平台的自动化建构系统,它使用一个名为 CMakeLists.txt 的文件来描述构建过程。CMake可以运行在Windows和Linux环境下，根据配置的编译器不同，生成符合所在操作系统的 Makefile 文件，在Windows下可以生成VS的工程文件系统。
将 CMake/bin 目录加入到系统环境变量Path 中

这是一个将开放式基金数据转换为 MIDI音乐的 C++ 程序示例。该程序将基金净值映射为 MIDI音符的音高

/funds/data/660008.csv 文件开头：
date,jz,ljjz
2016-01-04,1.1141,1.1141
2016-01-05,1.1161,1.1161
2016-01-06,1.1350,1.1350

1. midifile 项目--目录结构

2025/03/31  21:18    <DIR>          .
2025/03/31  21:18    <DIR>          ..
2025/03/18  00:31               185 .gitignore
2025/03/18  00:31             1,566 .travis.yml
2025/03/18  00:31             1,268 appveyor.yml
2025/03/31  21:42    <DIR>          bin
2025/03/31  22:15    <DIR>          build
2025/03/31  22:15             7,446 CMakeLists.txt
2025/03/18  00:31    <DIR>          include
2025/03/31  21:40    <DIR>          lib
2025/03/18  00:31             1,287 LICENSE.txt
2025/03/31  21:51             2,727 Makefile
2025/03/18  00:31             5,731 Makefile.library
2025/03/18  00:31             5,270 Makefile.programs
2025/03/31  21:22    <DIR>          obj
2025/03/18  00:31            80,092 README.md
2025/03/31  21:40    <DIR>          src
2025/03/31  21:57    <DIR>          tools
2025/03/18  00:31    <DIR>          visual-studio

2.编写 tools/fund2mid.cpp 程序，如下

#include <iostream>
#include <fstream>
#include <vector>
#include <string>
#include <cstring>
#include <algorithm>
#include <sstream>
#include "MidiFile.h"

using namespace std;
using namespace smf;

// CSV 数据结构/
struct FundData {
    string date;
    double jz;
};

// 解析 CSV 文件（适配三列格式）
vector<FundData> readCSV(const string& filename) {
    vector<FundData> data;
    ifstream file(filename);
    string line;

    // 跳过标题行
    getline(file, line);

    while (getline(file, line)) {
        // 使用字符串流分割三列
        stringstream ss(line);
        string date, jzStr, ljjzStr;

        // 按逗号分割字段
        getline(ss, date, ',');
        getline(ss, jzStr, ',');
        getline(ss, ljjzStr); // 第三列不需要使用

        if (date > "2024-01-01") {
            try {
                double jz = stod(jzStr);
                data.push_back({date, jz});
            } catch (const exception& e) {
                cerr << "解析错误: " << line << endl;
            }
        }
    }
    return data;
}

// 生成 MIDI 文件
void generateMIDI(const vector<double>& prices, const string& fcode) {
    MidiFile midiFile;
    midiFile.addTrack();
    midiFile.setTicksPerQuarterNote(480);// PPQ 需与 addNoteOff 参数一致

    // 计算价格范围
    auto [minIt, maxIt] = minmax_element(prices.begin(), prices.end());
    double minPrice = *minIt;
    double maxPrice = *maxIt;
    double priceRange = maxPrice - minPrice;

    // 音符范围配置
    int minNote = 48; // C3
    int maxNote = 84; // C5
    if (maxPrice / minPrice < 84.0/48.0) {
        maxNote = static_cast<int>(50 * (maxPrice / minPrice));
    }
    if (maxNote % 2 != 0) maxNote++;

    // 添加音符事件
    int track = 0;
    int channel = 0;
    int velocity = 80;
    int timeCounter = 0;
    int PPQ = 480; // 音符持续时间为 1个四分音符（480 ticks）

    for (double price : prices) {
        int pitch = (priceRange < 0.001)
            ? (maxNote + minNote) / 2
            : minNote + static_cast<int>((price - minPrice) / priceRange * (maxNote - minNote));

        midiFile.addNoteOn(track, timeCounter, channel, pitch, velocity);
        midiFile.addNoteOff(track, timeCounter + PPQ, channel, pitch);
        timeCounter += PPQ; // ms 间隔1拍, 单位：毫秒
    }

    // 保存文件
    string outputFile = "melo_" + fcode + ".mid";
    midiFile.write(outputFile);
    cout << "生成成功: " << outputFile << endl;
}

int main(int argc, char** argv) {
    if (argc != 2 || strlen(argv[1]) != 6) {
        cerr << "用法: " << argv[0] << " <6位基金代码>" << endl;
        return 1;
    }

    string fcode = argv[1];
    string csvFile = "/funds/data/" + fcode + ".csv";

    try {
        auto data = readCSV(csvFile);
        if (data.size() < 20) {
            cerr << "数据不足: " << data.size() << " < 20" << endl;
            return 2;
        }

        vector<double> prices;
        for (auto& entry : data) {
            prices.push_back(entry.jz);
        }

        generateMIDI(prices, fcode);
    } catch (const exception& e) {
        cerr << "错误: " << e.what() << endl;
        return 3;
    }

    return 0;
}

3.修改后的 CMakeLists.txt 关键部分

# 在 "Programs:" 部分添加你的可执行文件（大约第 66 行附近）
if(NOT BUILD_MIDILIBRARY_ONLY)

  # 已有的工具列表...
  add_executable(textmidi tools/textmidi.cpp)
  add_executable(toascii tools/toascii.cpp)
  add_executable(tobin tools/tobin.cpp)

  # 添加你的自定义程序
  add_executable(fund2mid tools/fund2mid.cpp)  # 新增行

  # 继续原有工具列表...
  add_executable(tobinary tools/tobinary.cpp)
  add_executable(todec tools/todec.cpp)

# ...

# 在链接库部分添加（大约第 136 行附近）
  target_link_libraries(textmidi midifile)
  target_link_libraries(toascii midifile)
  target_link_libraries(tobin midifile)

  target_link_libraries(fund2mid midifile)  # 新增行

  target_link_libraries(tobinary midifile)
  target_link_libraries(todec midifile)

4.完整修改说明

文件结构要求：

midifile/
├── CMakeLists.txt
├── include/
├── src/
└── tools/
    ├── fund2mid.cpp      # 你的程序源码
    ├── createmidifile.cpp
    └── ...其他工具源码

必要修改点：

在 add_executable 列表中添加：
add_executable(fund2mid tools/fund2mid.cpp)
在 target_link_libraries 部分添加：
target_link_libraries(fund2mid midifile)

编译验证：

# 生成构建系统
mkdir build
cd build
cmake ..

# 编译项目（Windows）
cmake --build . --config Release

适配注意事项

C++ 标准要求：
# 建议升级到 C++17（修改第 4 行）
set(CMAKE_CXX_STANDARD 17)
附件：完整的 CMakeLists.txt

运行 cmake --build . --config Release

D:\Music-soft\midifile-master\build> cmake --build . --config Release
适用于 .NET Framework MSBuild 版本 17.9.8+b34f75857

  midifile.vcxproj -> D:\Music-soft\midifile-master\build\Release\midifile.lib
  80off.vcxproj -> D:\Music-soft\midifile-master\build\Release\80off.exe
  asciimidi.vcxproj -> D:\Music-soft\midifile-master\build\Release\asciimidi.exe
  base642midi.vcxproj -> D:\Music-soft\midifile-master\build\Release\base642midi.exe
  binasc.vcxproj -> D:\Music-soft\midifile-master\build\Release\binasc.exe
  chaninfo.vcxproj -> D:\Music-soft\midifile-master\build\Release\chaninfo.exe
  createmidifile.vcxproj -> D:\Music-soft\midifile-master\build\Release\createmidifile.exe
  createmidifile2.vcxproj -> D:\Music-soft\midifile-master\build\Release\createmidifile2.exe
  deltatimes.vcxproj -> D:\Music-soft\midifile-master\build\Release\deltatimes.exe
  drumtab.vcxproj -> D:\Music-soft\midifile-master\build\Release\drumtab.exe
  durations.vcxproj -> D:\Music-soft\midifile-master\build\Release\durations.exe
  extractlyrics.vcxproj -> D:\Music-soft\midifile-master\build\Release\extractlyrics.exe
  fund2mid.cpp
D:\Music-soft\midifile-master\tools\fund2mid.cpp(42,39): warning C4101: “e”: 未引用的局部变量 [D:\Music-soft\midifile-master\bu
ild\fund2mid.vcxproj]
  fund2mid.vcxproj -> D:\Music-soft\midifile-master\build\Release\fund2mid.exe
  maxtick.vcxproj -> D:\Music-soft\midifile-master\build\Release\maxtick.exe
  mid2hex.vcxproj -> D:\Music-soft\midifile-master\build\Release\mid2hex.exe
  mid2mat.vcxproj -> D:\Music-soft\midifile-master\build\Release\mid2mat.exe
  mid2mtb.vcxproj -> D:\Music-soft\midifile-master\build\Release\mid2mtb.exe
  mid2svg.vcxproj -> D:\Music-soft\midifile-master\build\Release\mid2svg.exe
  midi2base64.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2base64.exe
  midi2binasc.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2binasc.exe
  midi2chords.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2chords.exe
  midi2melody.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2melody.exe
  midi2notes.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2notes.exe
  midi2skini.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2skini.exe
  midi2text.vcxproj -> D:\Music-soft\midifile-master\build\Release\midi2text.exe
  midicat.vcxproj -> D:\Music-soft\midifile-master\build\Release\midicat.exe
  mididiss.vcxproj -> D:\Music-soft\midifile-master\build\Release\mididiss.exe
  midimean.vcxproj -> D:\Music-soft\midifile-master\build\Release\midimean.exe
  midimixup.vcxproj -> D:\Music-soft\midifile-master\build\Release\midimixup.exe
  midirange.vcxproj -> D:\Music-soft\midifile-master\build\Release\midirange.exe
  midireg.vcxproj -> D:\Music-soft\midifile-master\build\Release\midireg.exe
  miditime.vcxproj -> D:\Music-soft\midifile-master\build\Release\miditime.exe
  midiuniq.vcxproj -> D:\Music-soft\midifile-master\build\Release\midiuniq.exe
  mts-type2.vcxproj -> D:\Music-soft\midifile-master\build\Release\mts-type2.exe
  mts-type9.vcxproj -> D:\Music-soft\midifile-master\build\Release\mts-type9.exe
  perfid.vcxproj -> D:\Music-soft\midifile-master\build\Release\perfid.exe
  readstatus.vcxproj -> D:\Music-soft\midifile-master\build\Release\readstatus.exe
  redexpress.vcxproj -> D:\Music-soft\midifile-master\build\Release\redexpress.exe
  removenote.vcxproj -> D:\Music-soft\midifile-master\build\Release\removenote.exe
  retick.vcxproj -> D:\Music-soft\midifile-master\build\Release\retick.exe
  shutak.vcxproj -> D:\Music-soft\midifile-master\build\Release\shutak.exe
  smfdur.vcxproj -> D:\Music-soft\midifile-master\build\Release\smfdur.exe
  stretch.vcxproj -> D:\Music-soft\midifile-master\build\Release\stretch.exe
  sysextest.vcxproj -> D:\Music-soft\midifile-master\build\Release\sysextest.exe
  temper.vcxproj -> D:\Music-soft\midifile-master\build\Release\temper.exe
  text2midi.vcxproj -> D:\Music-soft\midifile-master\build\Release\text2midi.exe
  textmidi.vcxproj -> D:\Music-soft\midifile-master\build\Release\textmidi.exe
  toascii.vcxproj -> D:\Music-soft\midifile-master\build\Release\toascii.exe
  tobin.vcxproj -> D:\Music-soft\midifile-master\build\Release\tobin.exe
  tobinary.vcxproj -> D:\Music-soft\midifile-master\build\Release\tobinary.exe
  todec.vcxproj -> D:\Music-soft\midifile-master\build\Release\todec.exe
  tohex.vcxproj -> D:\Music-soft\midifile-master\build\Release\tohex.exe
  type0.vcxproj -> D:\Music-soft\midifile-master\build\Release\type0.exe
  vlv.vcxproj -> D:\Music-soft\midifile-master\build\Release\vlv.exe

cd D:\Music-soft\midifile-master\build\Release
fund2mid.exe 660008
生成成功: melo_660008.mid

\python\mido_msg.py melo_660008.mid
\python\play_mid.py melo_660008.mid
