部署及使用seata

news2024/11/10 10:39:36

1.下载seata1.7.0.zip

2.上传至云服务器，使用unar工具解压

3.配置application.yml，主要配置如下参数

4.为seata执行mysql脚本

5.配置nacos配置中心

*6.启动seata服务器

问题：“cause:can not register RM,err:can not connect to services-server”

*7.SpringBoot整合Seata

问题：“BeanCreationException: Error creating bean with name 'dataSourceProperties' ”

1.下载seata1.7.0.zip

https://download.csdn.net/download/lmj3732018/88867613?ops_request_misc=%257B%2522request%255Fid%2522%253A%2522172355995516800180652535%2522%252C%2522scm%2522%253A%252220140713.130102334.pc%255Fall.%2522%257D&request_id=172355995516800180652535&biz_id=1&utm_medium=distribute.pc_search_result.none-task-download-2~all~first_rank_ecpm_v1~rank_v31_ecpm-7-88867613-null-null.142^v100^pc_search_result_base1&utm_term=seata&spm=1018.2226.3001.4187.8

2.上传至云服务器，使用unar工具解压

3.配置application.yml，主要配置如下参数

seata:
  config:
    # support: nacos, consul, apollo, zk, etcd3
    type: nacos
    nacos:
      server-addr:
      namespace:
      group:
      username:
      password:
      data-id:
  registry:
    # support: nacos, eureka, redis, zk, consul, etcd3, sofa
    type: nacos
    nacos:
      application:
      server-addr:
      group:
      namespace:
      cluster:
      username:
      password:
      context-path:
  store:
    # support: file 、 db 、 redis
    mode: db
    session:
      mode: db
    lock:
      mode: db
    db:
      datasource: druid
      db-type: mysql
      driver-class-name: com.mysql.cj.jdbc.Driver
      url:
      user:
      password:
      min-conn: 10
      max-conn: 100
      global-table: global_table
      branch-table: branch_table
      lock-table: lock_table
      distributed-lock-table: distributed_lock
      query-limit: 1000
      max-wait: 5000

4.为seata执行mysql脚本

5.配置nacos配置中心

transport.type=TCP
transport.server=NIO
transport.heartbeat=true
transport.enableClientBatchSendRequest=false
transport.threadFactory.bossThreadPrefix=NettyBoss
transport.threadFactory.workerThreadPrefix=NettyServerNIOWorker
transport.threadFactory.serverExecutorThreadPrefix=NettyServerBizHandler
transport.threadFactory.shareBossWorker=false
transport.threadFactory.clientSelectorThreadPrefix=NettyClientSelector
transport.threadFactory.clientSelectorThreadSize=1
transport.threadFactory.clientWorkerThreadPrefix=NettyClientWorkerThread
transport.threadFactory.bossThreadSize=1
transport.threadFactory.workerThreadSize=default
transport.shutdown.wait=3
#my-tx-groip需要记住，后面要用
service.vgroupMapping.my_tx_group=default
service.default.grouplist=0.0.0.0:8091
service.enableDegrade=false
service.disableGlobalTransaction=false
client.rm.asyncCommitBufferLimit=10000
client.rm.lock.retryInterval=10
client.rm.lock.retryTimes=30
client.rm.lock.retryPolicyBranchRollbackOnConflict=true
client.rm.reportRetryCount=5
client.rm.tableMetaCheckEnable=false
client.rm.tableMetaCheckerInterval=60000
client.rm.sqlParserType=druid
client.rm.reportSuccessEnable=false
client.rm.sagaBranchRegisterEnable=false
client.tm.commitRetryCount=5
client.tm.rollbackRetryCount=5
client.tm.defaultGlobalTransactionTimeout=60000
client.tm.degradeCheck=false
client.tm.degradeCheckAllowTimes=10
client.tm.degradeCheckPeriod=2000
store.mode=db
store.publicKey=
store.file.dir=file_store/data
store.file.maxBranchSessionSize=16384
store.file.maxGlobalSessionSize=512
store.file.fileWriteBufferCacheSize=16384
store.file.flushDiskMode=async
store.file.sessionReloadReadSize=100
store.db.datasource=druid
store.db.dbType=mysql
#数据库修改上面配置的位置
store.db.driverClassName=com.mysql.cj.jdbc.Driver
store.db.url=
store.db.user=
store.db.password=
#--------------#
store.db.minConn=5
store.db.maxConn=30
store.db.globalTable=global_table
store.db.branchTable=branch_table
store.db.queryLimit=100
store.db.lockTable=lock_table
store.db.maxWait=5000
store.redis.mode=single
store.redis.single.host=127.0.0.1
store.redis.single.port=6379
store.redis.maxConn=10
store.redis.minConn=1
store.redis.maxTotal=100
store.redis.database=0
store.redis.password=
store.redis.queryLimit=100
server.recovery.committingRetryPeriod=1000
server.recovery.asynCommittingRetryPeriod=1000
server.recovery.rollbackingRetryPeriod=1000
server.recovery.timeoutRetryPeriod=1000
server.maxCommitRetryTimeout=-1
server.maxRollbackRetryTimeout=-1
server.rollbackRetryTimeoutUnlockEnable=false
client.undo.dataValidation=true
client.undo.logSerialization=jackson
client.undo.onlyCareUpdateColumns=true
server.undo.logSaveDays=7
server.undo.logDeletePeriod=86400000
client.undo.logTable=undo_log
client.undo.compress.enable=true
client.undo.compress.type=zip
client.undo.compress.threshold=64k
log.exceptionRate=100
transport.serialization=seata
transport.compressor=none
metrics.enabled=false
metrics.registryType=compact
metrics.exporterList=prometheus
metrics.exporterPrometheusPort=9898

*6.启动seata服务器

../bin/seata-server.sh -h <真实ip>

问题：“cause:can not register RM,err:can not connect to services-server”

这个问题是因为在nacos里注册的网段是内网，而外部服务无法访问

*7.SpringBoot整合Seata

依赖项：

        <!--seata所需-->
        <dependency>
            <groupId>com.alibaba.cloud</groupId>
            <artifactId>spring-cloud-alibaba-seata</artifactId>
            <version>2.2.0.RELEASE</version>
            <exclusions>
                <exclusion>
                    <groupId>io.seata</groupId>
                    <artifactId>seata-spring-boot-starter</artifactId>
                </exclusion>
            </exclusions>
        </dependency>

        <dependency>
            <groupId>io.seata</groupId>
            <artifactId>seata-spring-boot-starter</artifactId>
            <version>1.7.0-native-rc2</version>
        </dependency>

        <!--mysql-->
        <dependency>
            <groupId>com.mysql</groupId>
            <artifactId>mysql-connector-j</artifactId>
            <scope>runtime</scope>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-jpa</artifactId>
        </dependency>

配置 yml：

seata:
  enabled: true
  #Seata 事务组编号，用于TC集群
  #要和 service.vgroupMapping.my_tx_group=default 中配置的相同
  tx-service-group: my_tx_group
  service:
    vgroup-mapping:
      my_tx_group: default
  ## 关闭自动代理
  enable-auto-data-source-proxy: false
  config: #配置中心，从nacos获取配置
    type: nacos
    nacos:
      server-addr:  #nacos地址
      group: SEATA_GROUP
      data-id: seataServer.properties
      username:
      password:

  registry: #TC服务注册中心的配置，微服务根据这些信息去注册中心获取tc服务地址
    type: nacos #注册中心类型 nacos
    nacos:
      application: seata-server #seata服务名称
      server-addr:  #nacos地址
      group: SEATA_GROUP #seata组，与seata所在组保持一致
      username:
      password:
  application-id: ${spring.application.name}

配置数据源代理：

@Configuration
public class DataSourceConfig {

    @Bean
    @Primary
    public DataSource dataSource(DataSourceProperties properties) {
        DataSource dataSource = properties.initializeDataSourceBuilder().build();
        return new DataSourceProxy(dataSource);
    }
}
